9N6A-02R01
Indexable Face Mill; 2.642″ Dia. × 3/4″ Shank Dia. × 1-3/4″ OAL × 0.31″ LOC ; 4 Inserts ; 44.1 Degrees
| Cutting Diameter (DC/DCX) | 2.642″ | Arbor Style | A |
| Cutting Diameter (DC) | 2″ | Coolant Supply Property (CSP) | External |
| Cutting Diameter Maximum (DCX) | 2.642″ | Body Material | Steel |
| Cutting Item Count (CICT) | 4 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 0.31″ | Application | | Chamfering | Facing | Slanted Shoulder & Chamfer | |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Measurement Type | Inch |
| Overall Length (OAL) | 1-3/4″ | Tool Cutting Edge Angle (KAPR) | 44.1 Degrees |
| Hub Diameter (DHUB) | 2.48″ |
Product Features
| Country of Origin | Usa |
Shipping Info
Package Weight
0.003
