SWMT1506ZER-MT AH3225
| Applicable Material | | Steel | Stainless Steel | | Grade | AH3225 |
| Application | | High Feed Milling | | Maximum Feed per Tooth (fz(max)) | 0.0787 in/tooth |
| Corner Radius (RE) | 0.0787″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.098″ | Minimum Feed per Tooth (fz(min)) | 0.0118 in/tooth |
| Insert Width (W1) | 0.627″ | Number of Cutting Edges | 4 |
| Inscribed Circle Diameter (IC) | 0.627″ | Cutting Edge Effective Length (LE) | 0.627″ |
| Insert Thickness (S) | 0.268″ | Measurement Type | Inch |
| Coating | TiAlSiCrN | Body Material | Carbide |
Product Features
| Family Description | Single-sided square insert with MT chipbreaker. Strong cutting edge type. | Country of Origin | JAPAN |
