5G6Q-25R30
Indexable Face Mill; 2-1/2″ Dia. × 3/4″ Shank Dia. × 2″ OAL × 1/4″ LOC ; 4 Inserts ; 30 Degrees
| Cutting Diameter (DC/DCX) | 2-1/2″ | Arbor Style | A |
| Cutting Diameter (DC) | 1.592″ | Ramping Angle Maximum (RMPX) | 2.5 Degrees |
| Cutting Diameter Maximum (DCX) | 2-1/2″ | Coolant Supply Property (CSP) | External |
| Cutting Item Count (CICT) | 4 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 1/4″ | Application | | Facing | Helical Interpolation | Rampdown | Shouldering | Slanted Shoulder & Chamfer | |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Measurement Type | Inch |
| Overall Length (OAL) | 2″ | Tool Cutting Edge Angle (KAPR) | 30 Degrees |
| Hub Diameter (DHUB) | 2.48″ |
Product Features
| Family Description | 30° Mid-feed rougher Three different insert edge preparations provide application flexibility Extremely free cutting! Excellent high feed performance & economy! | Country of Origin | Germany |
Shipping Info
Package Weight
0.003
