5G6Q-50R01
Indexable Face Mill; 5″ Dia. × 1-1/2″ Shank Dia. × 2-1/2″ OAL × 0.106″ LOC ; 8 Inserts ; 12 Degrees
| Cutting Diameter (DC/DCX) | 5″ | Arbor Style | A |
| Cutting Diameter (DC) | 4.144″ | Ramping Angle Maximum (RMPX) | 1.2 Degrees |
| Cutting Diameter Maximum (DCX) | 5″ | Coolant Supply Property (CSP) | External |
| Cutting Item Count (CICT) | 8 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.106″ | Application | | Facing | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slanted Shoulder & Chamfer | |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Measurement Type | Inch |
| Overall Length (OAL) | 2-1/2″ | Tool Cutting Edge Angle (KAPR) | 12 Degrees |
| Hub Diameter (DHUB) | 2.48″ |
Product Features
| Family Description | 12° Hi-feed rougher Three different insert edge preparations provide application flexibility Extremely free cutting! Excellent high feed performance & economy! 8″ and 10″ diameter tools do NOT have coolant through. | Country of Origin | USA |
Shipping Info
Package Weight
0.014
