DP5G-20R01
Indexable Face Mill; 2″ Dia. × 3/4″ Shank Dia. × 1-5/8″ OAL × 0.06″ LOC ; 5 Inserts ; 21 Degrees
| Cutting Diameter (DC/DCX) | 2″ | Arbor Style | A |
| Cutting Diameter (DC) | 1.468″ | Ramping Angle Maximum (RMPX) | 0.6 Degrees |
| Cutting Diameter Maximum (DCX) | 2″ | Coolant Supply Property (CSP) | External |
| Cutting Item Count (CICT) | 5 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.06″ | Application | | Facing | Helical Interpolation | Rampdown | Slotting | |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Measurement Type | Inch |
| Overall Length (OAL) | 1-5/8″ | Tool Cutting Edge Angle (KAPR) | 21 Degrees |
| Hub Diameter (DHUB) | 2.48″ |
Product Features
| Country of Origin | Germany |
Shipping Info
Package Weight
0.849
