VK6V-03R02
Indexable Face Mill; 3″ Dia. × 1″ Shank Dia. × 2-3/8″ OAL × 0.46″ LOC ; 5 Inserts
| Cutting Diameter (DC/DCX) | 3″ | Hub Diameter (DHUB) | 2.48″ |
| Cutting Diameter (DC) | 3″ | Arbor Style | A |
| Cutting Diameter Maximum (DCX) | 3″ | Coolant Supply Property (CSP) | External |
| Cutting Item Count (CICT) | 5 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.46″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 1″ | Application | | Facing | Shouldering | Slotting | |
| Overall Length (OAL) | 2-3/8″ | Measurement Type | Inch |
Product Features
| Family Description | .46″ Max. depth of cut .23″ Max. depth of cut at 90° Insert with up to 8 indexes (4 RH / 4 LH) Inserts with radii or chamfer | Country of Origin | Usa |
Shipping Info
Package Weight
0.005
