TJ5N-80R01
Indexable Face Mill; 8″ Dia. × 2-1/2″ Shank Dia. × 2.48″ OAL × 0.59″ LOC ; 14 Inserts ; 90 Degrees
| Cutting Diameter (DC/DCX) | 8″ | Arbor Style | A |
| Cutting Diameter (DC) | 8″ | Coolant Supply Property (CSP) | External |
| Cutting Item Count (CICT) | 14 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.59″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 2-1/2″ | Application | | Facing | Helical Interpolation | Rampdown | Shouldering | Slotting | |
| Overall Length (OAL) | 2.48″ | Measurement Type | Inch |
| Hub Diameter (DHUB) | 2.48″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
Product Features
| Family Description | Insert corners: .015″, .031″, .062″, .094″ R | Country of Origin | Usa |
Shipping Info
Package Weight
0.028
