T490 FLN D5.0-10-1.5-16
| Cutting Diameter (DC/DCX) | 5″ | Master Insert Identification (MIID) | T490 LNHT 160708PNR |
| Cutting Diameter (DC) | 5″ | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Item Count (CICT) | 10 | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.63″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Application | | Facing | Shouldering | Slotting | |
| Overall Length (OAL) | 2-1/2″ | Measurement Type | Inch |
| Hub Diameter (DHUB) | 3.307″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Arbor Style | B | Tool Type | 90° Facemills |
Product Features
| Family Description | HELITANG T490 Line, 90° face mills carrying T490 LNMT 16... tangentially clamped inserts with 4 long (.630″) helical cutting edges | Country of Origin | Israel |
| Remarks | When machining slots, regular pitch cutters should be used. |
Shipping Info
Package Weight
6.096
