DIN69871 40 SRKIN 10X80 B
| Connection Diameter Machine Side (DCONMS) | 25 mm | Shank Standard | DIN69871 |
| Connection Diameter Workpiece Side (DCONWS) | 10 mm | Application | | DIN 69871 (ISO7388 1) | SHRINKIN | |
| Shank Size (SS) | 40 | Usable Length (LU) | 60.9 mm |
| Body Length (LB) | 50.5 mm | Series/List # | SHRINK |
| Body Diameter (BD) | 25 mm | Measurement Type | Metric |
| Protruding Length (LPR) | 80 mm | Body Material | Steel |
| Overall Length (OAL) | 150 mm |
Product Features
| Family Description | Thermal shrink chucks with integral DIN 69871 form AD taper shank for solid carbide HSS and steel tools with h6 tolerance. | Country of Origin | Israel |
| Remarks | Use only inductive heating device for SRKIN holders B is the designation for coolant through flange ISCAR cannot guarantee an unbalance value less than 1 gr x mm For shrink units information, Click on "More Info" |
Shipping Info
Package Weight
2.447
