HSK E63 SRK10X80
| Connection Diameter Machine Side (DCONMS) | 25 mm | Shank Standard | HSK A |
| Connection Diameter Workpiece Side (DCONWS) | 10 mm | Application | | HSK | SHRINKIN | |
| Shank Size (SS) | 63 | Usable Length (LU) | 80 mm |
| Body Length (LB) | 60 mm | Series/List # | SHRINK |
| Body Diameter (BD) | 25 mm | Measurement Type | Metric |
| Protruding Length (LPR) | 106 mm | Body Material | Steel |
| Overall Length (OAL) | 150 mm |
Product Features
| Family Description | SHRINKIN, thermal chuck collets with HSK DIN69893 Form E tapered shanks for solid carbide tools only. | Country of Origin | Israel |
| Remarks | A cooling tube must be used with all coolant through HSK spindles (should be ordered separately). To be used for carbide tools only. For shank dimensions, Click on "More Info". |
Shipping Info
Package Weight
2.050
