| Thread Diameter Size (TDZ) | MF20 | Standard | DIN 374 |
| Thread Pitch (TP) | 1.5 mm | Tool Type | Machine Through Hole Taps |
| Thread Standard | THFT | | Coating | Uncoated |
| Overall Length (OAL) | 4.921″ | Drive Size (DRVS) | 0.472″ |
| Thread Cutting Part Length (THL) | 0.945″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 0.63″ | Grade | HE |
| Flute Count (NOF) | 4 | Thread Size | F20 × 1.5 |
| Application | | Taps for Deep Through Hole | Taps for Short Through Hole | | Body Material | HSS |
| Cutting Edge Material | HSS | Thread Form Type (THFT) | M60 |
Product Features
| Family Description | DIN 13 HSSE 5% Co Gun Point Machine Taps - ISO Metric Fine Threads for a Wide Range of Materials | Country of Origin | Hungary |
Shipping Info
Package Weight
200
