| Thread Diameter Size (TDZ) | M8 | Tool Type | Machine Blind Hole Taps |
| Thread Pitch (TP) | 1.25 mm | Coating | Steam tempered |
| Thread Standard | THFT | | Coolant Supply Property (CSP) | External |
| Overall Length (OAL) | 3.543″ | Measurement Type | Inch |
| Thread Cutting Part Length (THL) | 0.591″ | Grade | HEST |
| Usable Length (LU) | 1.38″ | Connection Code Machine Side (CCMS) | Cylindrical |
| Connection Diameter Machine Side (DCONMS) | 0.315″ | Thread Form Type (THFT) | M60 |
| Flute Count (NOF) | 3 | Application | | Deep Hole with Short Thread | Taps for Deep Blind Hole | Taps for Short Blind Hole | |
| Flute Helix Angle (FHA) | 40 Degrees | Body Material | HSS |
| Cutting Edge Material | HSS | Drive Size (DRVS) | 0.244″ |
| Standard | DIN 371 | Thread Size | 8 × 1.25 |
Product Features
| Family Description | HSS straight flute machine taps - ISO metric coarse threads, according to DIN 13, for low Carbone Steel | Country of Origin | Hungary |
Shipping Info
Package Weight
0.068
