2F5D050R00
Indexable Face Mill; 2.0079″ Dia. × 0.866″ Shank Dia. × 1.575″ OAL × 0.012″ LOC ; 7 Inserts ; 110 Degrees
| Cutting Diameter (DC/DCX) | 2.0079″ | Overall Length (OAL) | 1.575″ |
| Cutting Diameter (DC) | 1.968″ | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 2.0079″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 7 | Application | | Facing | Shouldering | |
| Depth of Cut Maximum (APMX) | 0.012″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 0.866″ | Tool Cutting Edge Angle (KAPR) | 110 Degrees |
Product Features
| Family Description | 0.3 mm Max Depth of Cut Insert corners: 0.2, 0.4 & 0.8 mm Finishes as good as 15 Ra Carbide, Cermet, CBN & PCD insert offerings Capable of undercutting a relief into a 90° shoulder | Country of Origin | Germany |
Shipping Info
Package Weight
349
