CART 05DRB5 ID8
| Tool Type | 90° Facemills for Al. & HTA | Cutting Edge Material | PCD |
| Width (W) | 11 mm | Applicable Material | | Aluminum / Non-Ferrous Materials | |
| Measurement Type | Metric | Minimum Feed per Tooth (fz(min)) | 0.08 mm/tooth |
| Application | | Facing | | Maximum Feed per Tooth (fz(max)) | 0.12 mm/tooth |
| Overall Length (OAL) | 26.5 mm | Corner Radius (RE) | 0.4 mm |
| Body Material | Carbide | Depth of Cut Maximum (APMX) | 3 mm |
| Grade | ID8 |
Product Features
| Family Description | PCD tipped cartridges for SPN D face mills | Country of Origin | Italy |
