MTECH 0806D14 1.25ISO IC902
Thread Mill; M8 × 1.25 mm ; 8 mm Shank Dia. × 64 mm OAL ; Carbide ; AlTiN ; IC902
| Thread Size | M8 | Application | | Internal Thread Milling | |
| Thread Pitch (TP) | 1.25 mm | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Thread Standard | MC |MF |THFT | | Cutting Edge Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 8 mm | Measurement Type | Metric |
| Cutting Diameter (DC) | 6 mm | Grade | IC902 |
| Overall Length (OAL) | 64 mm | Tool Type | Solid carbide thread mills |
| Flute Count (NOF) | 4 | Depth of Cut Maximum (APMX) | 13.7 mm |
| Shank Type | Round | Body Material | Carbide |
| Coating | AlTiN | Thread Form Type (THFT) | M60 |
Product Features
| Family Description | Small diameter solid carbide internal ISO profile threading and chamfering endmills, for hard materials up to 62 HRC, high temperature alloys and titanium alloys. High cutting speeds, low cutting forces resulting in accurate thread. | Country of Origin | Israel |
Shipping Info
Package Weight
0.044
