| Thread Pitch (TP) | 1.5 mm | Cutting Edge Material | Carbide |
| Thread Standard | MF |THFT | | Usable Length (LU) | 0.9764″ |
| Connection Diameter Machine Side (DCONMS) | 0.394″ | Measurement Type | Inch |
| Cutting Diameter (DC) | 0.386″ | Grade | IC908 |
| Overall Length (OAL) | 2.874″ | Tool Type | Solid carbide thread mills |
| Flute Count (NOF) | 5 | Depth of Cut Maximum (APMX) | 0.9764″ |
| Shank Type | Round | Body Material | Carbide |
| Coating | TiAlN | Connection Code Machine Side (CCMS) | Cylindrical |
| Application | | Internal Thread Milling | | Thread Form Type (THFT) | M60 |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
Product Features
| Family Description | Solid carbide internal threading endmill step release, lead x2 with coolant hole, used for ISO thread profile | Country of Origin | Israel |
Shipping Info
Package Weight
76
