AVC-D40-DDMNL-15
Int. Turning Tool ; 1.968″ OAL ; 1.575″ Shank Dia. ; 1.968″ LF ; 4.331″ Min Bore Dia. ; Steel
| Connection Diameter Machine Side (DCONMS) | 1.575″ | Coolant Supply Property (CSP) | Coolant Thru |
| Functional Length (LF) | 1.968″ | Application | | Int. 55° Diamond 48° Approach | |
| Overall Length (OAL) | 1.968″ | Rake Angle Axial (GAMP) | -10.5 Degrees |
| Functional Width (WF) | 0.433″ | Rake Angle Radial (GAMF) | 0 Degrees |
| Master Insert Identification (MIID) | DNM# 442(150608) | Body Material | Steel |
| Minimum Bore Diameter (DMIN) | 4.331″ | Measurement Type | Inch |
| Cutting Direction (HAND) | Left Hand |
Product Features
| Family Description | Interchangeable boring heads carrying 55° rhombic inserts. | Country of Origin | Israel |
Shipping Info
Package Weight
0.613
