TECP120H4L-24/38W12CF-R06
SQ End Mill; 12 mm Dia. × 24 mm LOC × 12 mm Shank Dia. × 83 mm OAL ; 0.6 mm RE ; 4 FL ; Carbide ; AlTiN
| Cutting Diameter (DC) | 12 mm | Applicable Material | Stainless Steel | Super-Alloys / Titanium |
| Connection Diameter Machine Side (DCONMS) | 12 mm | Application | Roughing | Counter Boring | Drilling | Hole Enlarging | Pocket Milling | Ramping | Shoulder Milling | Slot Milling |
| Depth of Cut Maximum (APMX) | 24 mm | Corner Radius (RE) | 0.6 mm |
| Overall Length (OAL) | 83 mm | Grade | AH725 |
| Cutting Edge Material | Carbide | Head Length (LH) | 38 mm |
| Coating | AlTiN | Neck Length (LN) | 38 mm |
| Flute Count (NOF) | 4 | Tool Type | Center Cut |
| Flute Helix Angle (FHA) | 30 Degrees | Decimal Equivalent | 0.035″ |
| Shank Type | Weldon | Measurement Type | Metric |
| End Shape | Corner Radius | Shank Size (SS) | 12 mm |
Product Features
| Family Description | Chatter free 4 flute solid carbide roughing endmills with 35-37 deg different helix and long chip splitting cutting edges for high stock removal rates. Mainly for machining stainless steel and high temperature alloys. | Country of Origin | Israel |
Shipping Info
Package Weight
0.8
