MS2MRBD1200R200
Corner Radius End Mill; 12 mm Dia. × 24 mm LOC × 12 mm Shank Dia. × 75 mm OAL ; 2 FL ; TiAlN ; Series MS2MRB
| Cutting Diameter (DC) | 12 mm | End Shape | Corner Radius |
| Connection Diameter Machine Side (DCONMS) | 12 mm | Corner Radius (RE) | 2 mm |
| Depth of Cut Maximum (APMX) | 24 mm | Peripheral Effective Cutting Edge Count (ZEFP) | 2 |
| Overall Length (OAL) | 75 mm | Length Group | Medium |
| Coating | TiAlN | Measurement Type | Metric |
| Flute Count (NOF) | 2 | Series/List # | MS2MRB |
| Flute Helix Angle (FHA) | 30 Degrees |
Product Features
| Country of Origin | Japan |
Shipping Info
Package Weight
.990
