1″ Dia. × 1″ Shank × 1-1/8″ DOC × 38 mm OAL, Carbide, TiAlN, 2 Flute, Corner Radius, Solid End Mill
Corner Radius End Mill; 1″ Dia. × 1-1/8″ LOC × 1″ Shank Dia. × 38 mm OAL ; 2 FL ; Carbide ; AlTiN ; Series VG446
| Cutting Diameter (DC) | 1″ | End Shape | Corner Radius |
| Connection Diameter Machine Side (DCONMS) | 1″ | Usable Length (LU) | 16 mm |
| Depth of Cut Maximum (APMX) | 1-1/8″ | Tool Type | Center Cut |
| Overall Length (OAL) | 38 mm | Style | Corner Radius |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | AlTiN | Series/List # | VG446 |
| Flute Count (NOF) | 2 | Corner Radius (RE) / Chamfer Width (CHW) | 0.12″ |
| Shank Type | Round |
Product Features
| Remarks | •Solid Carbide 2-Flute Square End Single End Mills •Used for general purpose milling in most materials of medium hardness such as steel, brass, iron and non-ferrous materials •Made from premium submicron grain carbide | Country of Origin | USA |
Shipping Info
Package Length
5.95000
Package Width
1.40000
Package Height
1.35000
Package Weight
1.9300
