ECSI-E-3 437-500-C437 IC900
SQ End Mill; 0.437″ Dia. × 1/2″ LOC × 0.437″ Shank Dia. × 2-3/4″ OAL ; 3 FL ; Carbide ; AlTiN
| Cutting Diameter (DC) | 0.437″ | Application | Counter Boring | Drill Mill | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slotting |
| Connection Diameter Machine Side (DCONMS) | 0.437″ | Ramping Angle Maximum (RMPX) | 5 Degrees |
| Depth of Cut Maximum (APMX) | 1/2″ | Grade | IC900 |
| Overall Length (OAL) | 2-3/4″ | Neck Diameter (DN) | 0.41″ |
| Cutting Edge Material | Carbide | Tool Type | Solid carbide center cutting endmills 90 Degrees |
| Coating | AlTiN | Maximum Feed per Tooth (fz(max)) | 0.0039 ″/tooth |
| Flute Count (NOF) | 3 | Minimum Feed per Tooth (fz(min)) | 0.0012 ″/tooth |
| Flute Helix Angle (FHA) | 38 Degrees | Body Material | Carbide |
| Shank Type | Round | Decimal Equivalent | 0.437″ |
| End Shape | Square | Measurement Type | Inch |
| Usable Length (LU) | 1″ | Connection Code Machine Side (CCMS) | Cylindrical |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Hi Temp Alloys | |
Product Features
| Family Description | 3 flute, 38° helix, short solid carbide endmill | Country of Origin | Israel |
Shipping Info
Package Weight
0.212
