22J3X-20025D1R01
| Application | | Facing | Shouldering | Slotting | | Number of Teeth | 16 |
| Cutting Item Count (CICT) | 5 | Coolant Supply Property (CSP) | External Coolant |
| Depth of Cut Maximum (APMX) | 2.16″ | Arbor Style | Arbor Hole |
| Cutting Diameter (DC) | 2″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Measurement Type | Inch |
| Flute Count (NOF) | 5 | Body Material | Steel |
| Overall Length (OAL) | 3″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Cutting Length | 2.16″ |
Product Features
| Family Description | Inch corners: .015″, .031″, .062″, .093″, .125″ R Metric corners: 3 mm, 4 mm R | Country of Origin | Usa |
Shipping Info
Package Weight
0.003
