22N3X-13020D3R01
| Application | | Chamfering | Slanted Shoulder & Chamfer | | Number of Teeth | 16 |
| Cutting Item Count (CICT) | 3 | Coolant Supply Property (CSP) | External Coolant |
| Depth of Cut Maximum (APMX) | 0.95″ | Arbor Style | Arbor Hole |
| Cutting Diameter (DC) | 1-3/8″ | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 1″ | Cutting Diameter Maximum (DCX) | 3.3″ |
| Flute Count (NOF) | 3 | Measurement Type | Inch |
| Overall Length (OAL) | 2″ | Body Material | Steel |
| Cutting Length | 1.72″ | Tool Cutting Edge Angle (KAPR) | 45 Degrees |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.005
