T490LNKD2.5-3.2-4-CAT50FT
| Depth of Cut Maximum (APMX) | 3.2″ | Cutting Depth | 4.96″ |
| Cutting Diameter (DC) | 2-1/2″ | Coolant Supply Property (CSP) | Coolant Thru |
| Connection Diameter Machine Side (DCONMS) | 1″ | Arbor Style | Arbor Hole |
| Flute Count (NOF) | 4 | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 2.699″ | Measurement Type | Inch |
| Cutting Length | 3.2″ | Body Material | Caterpillar |
| Number of Teeth | 28 | Tool Type | 90° Extended Flute Endmills |
Product Features
| Family Description | Basic units of modular extended flute endmills with Caterpillar tapered shanks carrying T490 LNMT/HT 1306 tangentially clamped Inserts. Can be used with many extension options. | Country of Origin | IL |
| Remarks | ae max for regular inserts, up to 0.10xD. ae max for -CS (chip splitting) inserts, up to 0.20xD Remove coolant plug screws (SR M6X..DIN916) prior to attaching extension units |
Shipping Info
Package Weight
10.3640
