P290 SM D4.-7-2.8-1.50-18
| Depth of Cut Maximum (APMX) | 2.8″ | Master Insert Identification (MIID) | P290 ACKT 1806 |
| Cutting Diameter (DC) | 4″ | Coolant Supply Property (CSP) | Coolant Thru |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Arbor Style | A |
| Flute Count (NOF) | 7 | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 3.94″ | Measurement Type | Inch |
| Cutting Length | 2.8″ | Tool Type | 90° Extended Flute Shell Mill |
| Number of Teeth | 28 |
Product Features
| Family Description | Extended flute shell mills carrying .472 and .708″ long edged inserts. | Country of Origin | IL |
| Remarks | Note: recommended ae up to 0.2xD |
Shipping Info
Package Weight
11.0250
