| Application | | Shouldering | | Master Insert Identification (MIID) | T490 LNMT 0804PNR |
| Cutting Item Count (CICT) | 24 | Coolant Supply Property (CSP) | Coolant Thru |
| Depth of Cut Maximum (APMX) | 44 mm | Arbor Style | A |
| Cutting Diameter (DC) | 40 mm | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 16 mm | Measurement Type | Metric |
| Flute Count (NOF) | 4 | Body Material | Steel |
| Overall Length (OAL) | 65 mm | Tool Type | 90° Extended flute shell mill |
| Cutting Length | 44 mm | Hub Diameter (DHUB) | 38 mm |
| Number of Teeth | 16 |
Product Features
| Family Description | Extended flute shell mills carrying T490 LNMT/HT 0804... tangentially clamped inserts (HELITANG T490 Line). | Country of Origin | Israel |
Shipping Info
Package Weight
1.116
