| Application | | Facing | Shouldering | | Number of Teeth | 16 |
| Peripheral Effective Cutting Edge Count (ZEFP) | 2 Teeth | Coolant Supply Property (CSP) | External Coolant |
| Cutting Item Count (CICT) | 2 | Arbor Style | Arbor Hole |
| Depth of Cut Maximum (APMX) | 1.14″ | Cutting Direction (HAND) | Right Hand |
| Cutting Diameter (DC) | 1″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1″ | Body Material | Steel |
| Flute Count (NOF) | 2 | Protruding Length (LPR) | 1-3/4″ |
| Overall Length (OAL) | 4″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Cutting Length | 1.14″ |
Product Features
| Family Description | Insert corners: .015″, .031″, .062″ R | Country of Origin | USA |
Shipping Info
Package Weight
0.832
