H490 SMD4.0-2.5-5-1.50*17
| Application | | Shouldering | | Number of Teeth | 20 |
| Cutting Item Count (CICT) | 20 | Master Insert Identification (MIID) | H490 ANKX 170604PNTR |
| Depth of Cut Maximum (APMX) | 2.42″ | Coolant Supply Property (CSP) | Through Hole |
| Cutting Diameter (DC) | 4″ | Arbor Style | A |
| Connection Diameter Machine Side (DCONMS) | 3.46″ | Cutting Direction (HAND) | Right Hand |
| Flute Count (NOF) | 5 | Measurement Type | Inch |
| Overall Length (OAL) | 3.35″ | Body Material | Steel |
| Cutting Length | 2.42″ | Tool Type | 90° Extended flute shell mill |
Product Features
| Family Description | Extended flute shell mills carrying H490 ANKX 17.. double-sided rectangular inserts with 4 helical cutting edges (HELIDO 490 LINE). | Country of Origin | Israel |
| Remarks | ae(max)=0.25xD for regular inserts, ae(max)=0.35xD for -CS (chip splitting) inserts. Inserts with corner radii larger than .031″ should only be used on the face of the cutter. |
Shipping Info
Package Weight
8.818
