| Depth of Cut Maximum (APMX) | 44 mm | Cutting Depth | 53 mm |
| Cutting Diameter (DC) | 40 mm | Coolant Supply Property (CSP) | Coolant Thru |
| Connection Diameter Machine Side (DCONMS) | 1″ | Arbor Style | Arbor Hole |
| Flute Count (NOF) | 4 | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 120 mm | Measurement Type | Metric |
| Cutting Length | 44 mm | Body Material | Round |
| Number of Teeth | 24 | Tool Type | 90° Extended Flute Endmills |
Product Features
| Family Description | Extended flute endmills carrying T490 LNMT/HT 08... tangentially clamped inserts. | Country of Origin | IL |
| Remarks | ae max for regular inserts, up to 0.25xD, ae max for -CS (chip splitting) inserts, up to 0.35xD |
Shipping Info
Package Weight
1.7440
