| Depth of Cut Maximum (APMX) | 82 mm | Cutting Depth | 107 mm |
| Cutting Diameter (DC) | 63 mm | Coolant Supply Property (CSP) | Coolant Thru |
| Connection Diameter Machine Side (DCONMS) | 1″ | Arbor Style | Arbor Hole |
| Flute Count (NOF) | 4 | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 2.699″ | Measurement Type | Metric |
| Cutting Length | 82 mm | Tool Type | 90° Extended Flute Endmills |
| Number of Teeth | 28 |
Product Features
| Family Description | Extended flute endmills with BT MAS-403 tapered shanks carrying T490 LNMT/LNHT 13... tangentially clamped inserts with 4 helical, 13 mm long cutting edges (HELITANG T490 Line). | Country of Origin | IL |
| Remarks | ae max for regular inserts, up to 0.20xD, ae max for -CS (chip splitting) inserts, up to 0.25xD |
Shipping Info
Package Weight
12.3720
