| Corner Radius (RE) | 0.0197″ | Applicable Material | | Cast Iron | Hard Materials | |
| Insert Thickness (S) | 0.187″ | Max. Grooving Feed (fg(max)) | 0.0059 ″/rev |
| Insert Length (INSL) | 0.683″ | Min. Grooving Feed (fg(min)) | 0.002 ″/rev |
| Cutting Depth Maximum (CDX) | 0.124″ | Tool Type | Groove-Turn Utility Inserts |
| Cutting Edge Material | Ceramic | Measurement Type | Inch |
| Grade | IN18 | Body Material | Carbide |
| Application | | Ext. Grooving | Pulley V Grooving | |
Product Features
| Family Description | Ceramic precision inserts for grooving multi V-ribbed pulleys | Country of Origin | Japan |
