| Applicable Material | | Steel | Stainless Steel | Cast Iron | | Fixing Hole Diameter (D1) | 0.217″ |
| Application | | Inserts | | Tool Type | Turn Positive Inserts |
| Corner Radius (RE) | 0.0315″ | Cutting Direction (HAND) | Neutral |
| Insert Thickness (S) | 0.242″ | Chip Breaker Type | AMT3C-TM |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | Ti-compound+Al2O3+TiN | Body Material | Carbide |
| Grade | T9215 | Cutting Edge Effective Length (LE) | 0.984″ |
Product Features
| Family Description | Positive 7 deg relief angle, M class, triangular insert with Y-PRISM's safe lock design. | Country of Origin | Japan |
| Remarks | Please note that 3C TCMT... insert is not recommended for pull face turning method (pulling the insert away from the part center). *Products are made by license; PrimeTurning is a proprietary technology of AB Sandvik Coromant. |
