VBB0625L63-BG-U02S10 AH750
End Mill Head; 5/8″ Dia. × 0.63″ LOC ; 2 FL ; Carbide ; TiAlN ; AH750
| Application | | Profile Milling | | Flute Helix Angle (FHA) | 0 Degrees |
| Cutting Diameter (DC) | 5/8″ | Grade | AH750 |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | | Coating | TiAlN |
| Flute Count (NOF) | 2 | Measurement Type | Inch |
| Corner Radius (RE) | 5/16″ | Cutting Edge Material | Carbide |
| Cutting Diameter Maximum (DCX) | 5/8″ | Tool Type | Solid ball nose |
| Depth of Cut Maximum (APMX) | 0.63″ | Body Material | Carbide |
| Functional Length (LF) | 0.752″ |
Product Features
| Family Description | Ball, 2 flutes, finishing, high accuracy h7, for hardened material | Country of Origin | ISRAEL |
| Remarks | Torque:Recommended torque (Nm) for clamping. Wrench sold separately. |
