TEC140B3-14W14-75 AH725
SQ End Mill; 14 mm Dia. × 14 mm LOC × 14 mm Shank Dia. × 75 mm OAL ; 3 FL ; Carbide ; TiAlN
| Cutting Diameter (DC) | 14 mm | Shank Type | Weldon |
| Connection Diameter Machine Side (DCONMS) | 14 mm | End Shape | Square |
| Depth of Cut Maximum (APMX) | 14 mm | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | |
| Overall Length (OAL) | 75 mm | Application | | Shoulder Milling | |
| Cutting Edge Material | Carbide | Grade | AH725 |
| Coating | TiAlN | Body Material | Carbide |
| Flute Count (NOF) | 3 | Measurement Type | Metric |
Product Features
| Family Description | 3 flute endmill, 45 deg helix angle, short type | Country of Origin | S.Korea |
Shipping Info
Package Weight
0.8
