| Application | | Shoulder Milling | Tapered shape interface | | Master Insert Identification (MIID) | TOMT15... |
| Peripheral Effective Cutting Edge Count (ZEFP) | 5 | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 35 | Measurement Type | Metric |
| Depth of Cut Maximum (APMX) | 97 mm | Body Material | Steel |
| Cutting Diameter (DC) | 100 mm | Tool Type | 90 Extended flute shell mill |
| Overall Length (OAL) | 165 mm |
Product Features
| Family Description | Square shoulder mills for roughing with triangular inserts, Main unit with BT tapered shanks. Up to 2 TLA15-S sub-units can be added on a TLA15 main unit to increase depth of cut. | Country of Origin | JAPAN |
Shipping Info
Package Weight
19.974
Related Documentation
The combination of TLA15 main units, TLA15-S sub-units and center bolts
