| Application | | Shoulder Milling | | Overall Length (OAL) | 3-1/4″ |
| Peripheral Effective Cutting Edge Count (ZEFP) | 4 | Master Insert Identification (MIID) | TO*T10... |
| Cutting Item Count (CICT) | 24 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 2.126″ | Measurement Type | Inch |
| Cutting Diameter (DC) | 2″ | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Tool Type | 90 Extended flute shell mill |
Product Features
| Family Description | Extended Flute square shoulder mills for roughing with TOMT10 triangular inserts | Country of Origin | Japan |
| Remarks | For setting NMJ inserts, click on "Product report". Coolant can be supplied from the end face of the centering location bore in the arbor. However, cannot be supplied from the center bolt. |
Shipping Info
Package Weight
2.198
