QC-1216X-F15-CHP
Turning Toolholder; 102.5 mm OAL × 12 mm Shank Height × 16 mm Shank Width ; Neutral ; Steel
| Shank Height (H) | 12 mm | Cutting Direction (HAND) | Neutral |
| Shank Width (B) | 16 mm | Application | | External grooving | For Miniature machining | Parting off | |
| Overall Length (OAL) | 102.5 mm | Body Material | Steel |
| Functional Length (LF) | 100 mm | Measurement Type | Metric |
| Functional Width (WF) | 21 mm |
Product Features
| Family Description | Stepped-head shank for modular heads, with high pressure coolant capability | Country of Origin | JAPAN |
| Remarks | Through coolant shank. For using internal coolant, please select both a through coolant head and a through coolant shank. |
Shipping Info
Package Weight
0.000
