JPVJ2NR082.33
Turning Toolholder; 4-3/4″ OAL × 1/2″ Shank Height × 1/2″ Shank Width × 0.9″ LH ; Right Hand ; Steel
| Shank Height (H) | 1/2″ | Cutting Direction (HAND) | Right Hand |
| Shank Width (B) | 1/2″ | Master Insert Identification (MIID) | VNMG2.330.5 |
| Overall Length (OAL) | 4-3/4″ | Application | | For 35deg Rhombic insert | For Miniature machining | |
| Functional Length (LF) | 4-3/4″ | Body Material | Steel |
| Head Length (LH) | 0.9″ | Measurement Type | Inch |
| Functional Width (WF) | 0″ |
Product Features
| Family Description | No-offset Back-clamp toolholder with 93 deg approach for 35 deg rhombic inserts VN**2.33... | Country of Origin | JAPAN |
| Remarks | Torque: Recommended torque (Nm) for clamping |
