EXLN04U1.25C1.25R05L
Indexable End Mill; 1-1/4″ Dia. × 0.157″ LOC × 1-1/4″ Shank Dia. × 8″ OAL ; Round Shank
| Cutting Diameter (DC/DCX) | 1-1/4″ | Master Insert Identification (MIID) | LNMX0405R4-MJ |
| Cutting Diameter (DC) | 1-1/4″ | Head Length (LH) | 5″ |
| Cutting Item Count (CICT) | 5 | Functional Length (LF) | 8″ |
| Depth of Cut Maximum (APMX) | 0.157″ | Tool Type | CUTTER - SHANK TYPE |
| Overall Length (OAL) | 8″ | Measurement Type | Inch |
| Shank Type | Round | Body Material | Steel |
| Application | | High Feed Milling | Profile Milling | | Shank Length (LS) | 3″ |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Cutting Diameter Maximum (DCX) | 1-1/4″ |
Product Features
| Family Description | Radius cutter with double-sided insert; Shank type | Country of Origin | JAPAN |
| Remarks | APMX may vary with insert type. |
Shipping Info
Package Weight
0.000
