EBP030LSE
Indexable End Mill; 30 mm Dia. × 45 mm LOC × 32 mm Shank Dia. × 350 mm OAL
| Cutting Diameter (DC/DCX) | 30 mm | Head Length (LH) | 100 mm |
| Cutting Diameter (DC) | 30 mm | Functional Length (LF) | 350 mm |
| Cutting Item Count (CICT) | 4 | Tool Type | Ball nose endmills |
| Depth of Cut Maximum (APMX) | 45 mm | Measurement Type | Metric |
| Overall Length (OAL) | 350 mm | Body Material | Steel |
| Application | | Profile Milling | | Shank Length (LS) | 250 mm |
| Connection Diameter Machine Side (DCONMS) | 32 mm | Cutting Diameter Maximum (DCX) | 30 mm |
| Master Insert Identification (MIID) | ZPET3006-MJ |
Product Features
| Family Description | Indexable ball-nose endmill for semi-finishing | Country of Origin | JAPAN |
Shipping Info
Package Weight
5.313
