TAN07R400U0150A07
Indexable Face Mill; 4.5118″ Dia. × 1-1/2″ Shank Dia. × 2″ OAL × 0.295″ LOC ; 7 Inserts
| Cutting Diameter (DC/DCX) | 4.5118″ | Master Insert Identification (MIID) | ONMU0705ANPN-MJ |
| Cutting Diameter (DC) | 4″ | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 4.5118″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 7 | Application | | Face Milling | |
| Depth of Cut Maximum (APMX) | 0.295″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Functional Length (LF) | 2″ |
| Overall Length (OAL) | 2″ | Tool Type | 45 Facemills |
Product Features
| Family Description | 45deg screw clamp type face mills with double sided octagonal or square inserts. | Country of Origin | Japan |
| Remarks | APMX may vary with insert type. |
Shipping Info
Package Weight
4.222
