TFE12300RU
Indexable Face Mill; 3.0685″ Dia. × 1″ Shank Dia. × 1.378″ OAL × 0.315″ LOC ; 4 Inserts
| Cutting Diameter (DC/DCX) | 3.0685″ | Master Insert Identification (MIID) | SEGW12X4ZEFR |
| Cutting Diameter (DC) | 3″ | Body Material | Steel |
| Cutting Diameter Maximum (DCX) | 3.0685″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 4 | Application | | Face Milling | |
| Depth of Cut Maximum (APMX) | 0.315″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1″ | Functional Length (LF) | 1.378″ |
| Overall Length (OAL) | 1.378″ | Tool Type | 90 Facemills |
Product Features
| Family Description | 85.5 deg face mills with screw clamped inserts for aluminum machining | Country of Origin | Japan |
| Remarks | APMX may vary with insert type. |
Shipping Info
Package Weight
1.74
