ASMT170532PDPR-MJ AH120
Milling Insert; ASMT170532PDPRMJ AH120 AH120 × 0.386″ Width × 0.22″ Thickness ; Carbide ; TiAlN
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Coating | TiAlN |
| Application | | Shoulder Milling | | Grade | AH120 |
| Insert Length (INSL) | 0.728″ | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 0.1259″ | Tool Type | Single sided Inserts |
| Depth of Cut Maximum (APMX) | 0.63″ | Number of Cutting Edges | 2 |
| Insert Width (W1) | 0.386″ | Cutting Edge Effective Length (LE) | 0.665″ |
| Inscribed Circle Diameter (IC) | 0.386″ | Measurement Type | Inch |
| Insert Thickness (S) | 0.22″ | Body Material | Carbide |
Product Features
| Family Description | High performance insert with MJ chipbreaker for general purpose | Country of Origin | Japan |
Shipping Info
Package Weight
0.021
