LNCQ0906N-100L AH120
Milling Insert; LNCQ0906N-100L AH120 AH120 × 1/2″ Width × 1/4″ Thickness ; Carbide ; TiAlN
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Wiper Edge Length (BS) | 0.311″ |
| Application | | Face Milling | | Coating | TiAlN |
| Insert Length (INSL) | 1/2″ | Grade | AH120 |
| Corner Radius (RE) | 0.0314″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.008″ | Tool Type | Mill Tangential Inserts |
| Insert Width (W1) | 1/2″ | Number of Cutting Edges | 4 |
| Inscribed Circle Diameter (IC) | 3/8″ | Measurement Type | Inch |
| Insert Thickness (S) | 1/4″ | Body Material | Carbide |
Product Features
| Family Description | Uniqly designed insert for highly accurate machining | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.258
