SPMR1605PPTR-MH GH330
Milling Insert; SPMR1605PPTR-MH GH330 GH330 × 0.63″ Width × 0.219″ Thickness ; Carbide ; TiCNO
| Applicable Material | | Steel | Stainless Steel | Cast Iron | | Coating | TiCNO |
| Corner Radius (RE) | 0.0314″ | Grade | GH330 |
| Depth of Cut Maximum (APMX) | 0.472″ | Cutting Edge Material | Carbide |
| Insert Width (W1) | 0.63″ | Tool Type | Single sided Inserts |
| Inscribed Circle Diameter (IC) | 0.63″ | Number of Cutting Edges | 4 |
| Insert Thickness (S) | 0.219″ | Measurement Type | Inch |
| Wiper Edge Length (BS) | 0.079″ | Body Material | Carbide |
Product Features
| Family Description | With tough cutting edge MH chipbreaker | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.373
