SDKR53ZSR-MJ GH330
Milling Insert; SDKR53ZSR-MJ GH330 ISO GH330 × 15.875 mm Width × 4.76 mm Thickness ; Carbide ; TiCNO
| Applicable Material | | Steel | Stainless Steel | Cast Iron | | Coating | TiCNO |
| Application | | Face Milling | | Grade | GH330 |
| Depth of Cut Maximum (APMX) | 6 mm | Cutting Edge Material | Carbide |
| Insert Width (W1) | 15.875 mm | Tool Type | Single sided Inserts |
| Inscribed Circle Diameter (IC) | 15.875 mm | Number of Cutting Edges | 4 |
| Insert Thickness (S) | 4.76 mm | Measurement Type | Metric |
| Wiper Edge Length (BS) | 2 mm | Body Material | Carbide |
Product Features
| Family Description | Square insert with 15deg relief angle and MJ chipbreaker, for 45 deg corner angle and large depth of cut | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.300
