DG1H-20R01
Indexable End Mill; 2″ Dia. × 0.098″ LOC × 3/4″ Shank Dia. × 1.575″ OAL
| Cutting Diameter (DC/DCX) | 2″ | Weight of Item (WT) | 0.73 Kg |
| Cutting Diameter (DC) | 1.324″ | Corner Radius (RE) | 0.177″ |
| Cutting Item Count (CICT) | 5 | Coolant Supply Property (CSP) | Coolant Thru |
| Depth of Cut Maximum (APMX) | 0.098″ | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 1.575″ | Measurement Type | Inch |
| Ramping Angle Maximum (RMPX) | 0.6 Degrees | Body Material | Steel |
| Application | | Facing | Helical Interpolation | Rampdown | | Connection Code Machine Side (CCMS) | Cylindrical |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Cutting Diameter Maximum (DCX) | 2″ |
Product Features
| Family Description | Strong secure wedge clamp system Excellent hi-feed performance & economy! | Country of Origin | S.Korea |
Shipping Info
Package Weight
2.028
