QSDR-3T26-060-CHP
Grooving Toolholder ; 0.098″ CW Min. ; 0.137″ CW Max. ; 1.024″ Max Depth ; Right Hand ; Steel
| Cutting Width Minimum (CWN) | 0.098″ | Cutting Direction (HAND) | Right Hand |
| Cutting Width Maximum (CWX) | 0.137″ | Application | | Face grooving | |
| Cutting Depth Maximum (CDX) | 1.024″ | Body Material | Steel |
| Functional Width (WF) | 0.295″ | Tool Type | Face Turning & grooving Tools |
| Functional Length (LF) | 2.819″ | Measurement Type | Inch |
Product Features
| Family Description | Deep face grooving adapter with high pressure coolant capability | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.000
