CCH32-W40
Parting Off Holder; 150 mm OAL × 21 mm Max Depth × 24.5 mm OAH ; Steel
| Shank Height (H) | 32 mm | Tool Type | Parting & Grooving Tools |
| Shank Width (B) | 3.2 mm | Work Piece Parting Diameter Maximum (CUTDIA) | 42 mm |
| Overall Length (OAL) | 150 mm | Cutting Direction (HAND) | Neutral |
| Cutting Depth Maximum (CDX) | 21 mm | Measurement Type | Metric |
| Overall Height (OAH) | 24.5 mm | Insert Seat Size Code (SSC) | 40 |
| Application | | Parting off | | Functional Width (WF) | 1.6 mm |
| Body Material | Steel | Tool Assembly Length (LTA) | 35 mm |
Product Features
| Family Description | Blades for parting off (for 2 corner insert) | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.282
