| Applicable Material | | Super-Alloys / Titanium | | Maximum Feed per Tooth (fz(max)) | 0.0079 ″/tooth |
| Application | | Shouldering | | Cutting Direction (HAND) | Neutral |
| Corner Radius (RE) | 0.0315″ | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.48″ | Tool Type | Double sided Inserts |
| Inscribed Circle Diameter (IC) | 0.512″ | Minimum Feed per Tooth (fz(min)) | 0.0028 ″/tooth |
| Insert Thickness (S) | 0.217″ | Number of Cutting Edges | 8 |
| Wiper Edge Length (BS) | 0.449″ | Measurement Type | Inch |
| Coating | TiB2 | Body Material | Carbide |
| Grade | IC716 |
Product Features
| Family Description | Double-sided square inserts with 4/8 cutting edges | Country of Origin | Israel |
Shipping Info
Package Weight
11.1
